Fully premixed condensing wall-hung boilers have become one of the mainstream choices for modern home heating due to their high efficiency and energy-saving advantages. Flue installation, as a core link for the stable operation of fully premixed condensing wall-hung boilers, directly determines the safety and energy efficiency performance of the equipment. Therefore, the installation specifications for the flue of fully premixed condensing wall-hung boilers must be strictly followed. Only by completing the flue installation in accordance with the specifications can problems such as poor smoke exhaust and condensed water backflow of fully premixed condensing wall-hung boilers be avoided, ensuring the long-term reliability of the home heating system.

Core Preparations Before Flue Installation of Fully Premixed Condensing Wall-Hung Boilers

Before starting the flue installation of fully premixed condensing wall-hung boilers, adequate preparation work is the basis for standard implementation, mainly involving two dimensions: flue selection and on-site survey.

1. Selection of Flue Material and Specification

The flue of fully premixed condensing wall-hung boilers needs to withstand high-temperature flue gas and condensed water corrosion. Therefore, stainless steel or corrosion-resistant special composite materials should be preferred for the material, and ordinary plastic or iron sheet pipes should be avoided. In terms of specifications, the flue diameter should be matched according to the rated power of the fully premixed condensing wall-hung boiler. Generally, the higher the power, the larger the flue diameter needs to be. For specific parameters, refer to the recommended parameters in the equipment manual to ensure that the smoke exhaust volume is consistent with the operation requirements of the equipment.

2. On-Site Survey and Planning for Installation

It is necessary to conduct an on-site survey in advance to determine the direction and penetration position of the flue. Priority should be given to the path of directly penetrating the external wall to reduce the number of flue bends (it is recommended not to exceed 2 times), so as to avoid increased smoke exhaust resistance due to too many bends. At the same time, it is necessary to confirm that there are no flammable materials (such as wooden furniture, curtains, etc.) around the installation location, and the safety distance from gas pipelines, wires and other facilities is not less than the requirements of the specifications to prevent potential safety hazards.

Key Specifications During Flue Installation of Fully Premixed Condensing Wall-Hung Boilers

During the installation process, details must be strictly controlled to ensure that each step conforms to the operating characteristics of fully premixed condensing wall-hung boilers, with focus on installation location, connection sealing and slope setting.

1. Rigid Requirements for Flue Installation Location

The flue outlet of fully premixed condensing wall-hung boilers should avoid areas with personnel activities (such as balconies, under windows), and the height from the ground should not be less than 2.5 meters to prevent flue gas from directly contacting the human body. If it needs to be installed on the external wall of a public area, it is necessary to ensure that the outlet is far away from the neighbor's windows or vents, and the horizontal distance is not less than 1.5 meters to avoid flue gas backflow into adjacent spaces. In addition, the flue is prohibited from passing through residential areas such as bedrooms and living rooms, and must pass through the external wall or special flue shaft.

2. Standard for Flue Connection and Sealing Operation

Special connectors should be used for splicing between each section of the flue, and tape or ordinary sealant is prohibited. During splicing, ensure that the interfaces are aligned, the gap does not exceed 0.5 mm, and then reinforce with high-temperature resistant seals to prevent flue gas leakage. For the connection part between the main unit of the fully premixed condensing wall-hung boiler and the flue, the original flange joint of the equipment should be used, and the screws should be tightened with uniform force to avoid interface loosening caused by uneven force, which affects the sealing effect.

3. Core Principle for Flue Slope Setting

Fully premixed condensing wall-hung boilers will generate condensed water during operation. Therefore, the flue should be set with a certain slope to ensure that the condensed water naturally flows to the condensed water collection device of the main unit, and water accumulation is prohibited. The slope direction should be inclined from the flue outlet to the main unit, and the slope value should not be less than 3° (that is, the flue drops by not less than 3 cm per meter). At the same time, avoid setting concave sections in the middle of the flue to prevent condensed water accumulation from causing pipeline corrosion or blockage.

Essential Inspections After Flue Installation of Fully Premixed Condensing Wall-Hung Boilers

After the installation is completed, multi-dimensional inspections are required to verify compliance and ensure that the fully premixed condensing wall-hung boiler can start safely, mainly including tightness, smoothness and safety protection inspections.

1. Flue Tightness Test

Turn off the fully premixed condensing wall-hung boiler, block the temporary sealing cover at the flue outlet, and then inject low-pressure air (pressure not exceeding 500 Pa) into the flue to observe the pressure gauge change. If the pressure drop does not exceed 5% within 5 minutes, it indicates that the tightness is qualified; if the pressure drops too fast, check each interface one by one and re-strengthen the seal until it meets the requirements, so as to prevent carbon monoxide risks caused by flue gas leakage.

2. Flue Smoothness Test

Start the fully premixed condensing wall-hung boiler, and after 10 minutes of operation, use a flue gas detector to detect the smoke exhaust speed at the flue outlet to ensure that it meets the rated smoke exhaust volume in the equipment manual. At the same time, observe whether the flue has vibration or abnormal noise. If there is poor smoke exhaust, check whether the flue has bending, blockage and other problems, and adjust or clean it in time to avoid equipment shutdown or energy efficiency reduction caused by blocked smoke exhaust.

3. Inspection of Safety Protection Measures

Confirm whether a protective sleeve is installed outside the flue (especially at the part passing through the wall) to prevent potential safety hazards caused by heat transfer from the wall; if the flue is installed outdoors, a rain cap should be installed at the outlet to prevent rainwater from entering the flue. In addition, check whether safety warning signs are posted around the flue to remind users not to block or modify the flue, ensuring long-term safe use.

Daily Maintenance Recommendations for Flue of Fully Premixed Condensing Wall-Hung Boilers

Standard daily maintenance can extend the service life of the flue and ensure the continuous and efficient operation of the fully premixed condensing wall-hung boiler. Focus on regular cleaning and damage inspection.

Regularly clean the dust and impurities inside the flue, it is recommended to do it once every six months. A special flue cleaning brush can be used to clean from the outlet to the main unit to avoid blockage of the pipeline due to accumulation of debris. At the same time, check whether the outside of the flue is corroded, deformed or the interface is loose every month. If damage is found, the damaged section should be replaced in time to prevent flue gas leakage or condensed water overflow caused by pipeline damage, which affects the normal operation of the fully premixed condensing wall-hung boiler.

To sum up, the installation specifications for the flue of fully premixed condensing wall-hung boilers are the core prerequisite for ensuring the safe and efficient operation of the equipment. Every step from preparation before installation to inspection after installation must be strictly implemented. Following the specifications can not only give full play to the energy-saving advantages of fully premixed condensing wall-hung boilers, but also avoid smoke exhaust hazards, providing a stable guarantee for the home heating system. For users, attaching importance to the flue installation specifications is also a key guarantee for home safety and heating experience.
